Condensate Pump

VCMA-20 Series Condensate Pump

Condensate Pump

VCMA-20 Series Condensate Pump

Avoid excess condensation from your HVAC equipment with Little Giant's VCMA-20 Series condensate pump. Used to move and direct the flow of condensation produced by boilers, furnaces, air conditioning systems, and hydroponic systems, the VCMA-20 condensate pump is ideal when gravity drainage is not possible or practical. Its state-of-the-art design features a vertical-type pump unit to fit in tight spaces requiring a smaller footprint.

Features & Benefits

  • 1/30 hp high-performance motor
  • ABS tank, motor cover, and volute
  • Stainless steel motor shaft
  • ½-gallon tank capacity
  • 20' of 3/8" clear tubing (554435 & 554461 only)
  • CSA certified to US and Canada standards

Overview


The VCMA-20 Series condnesate pump is driven by a 1/30 horsepower high-performance motor with a safety switch and features an ABS tank, motor cover, and volute with 20' lift. 20' of 3/8" durable, clear tubing resists crimping or kinking during operation. Includes 6' power cord.

Specifications


Capacity 80 gph @ 1'
Shut Off 20' (6.1 m) / 115 V
17' (5.2 m) / 230 V
Max. Liquid Temp. 140 °F (60 °C)
Discharge 3/8" barbed (9.5 mm)
Impeller Glass-filled Polypropylene
Electrical 115 V, 60 Hz, 1.5 A
230 V, 50/60 Hz, 0.5 A
Operation Automatic

Performance

Performance
Head GPH (LPH)
1' 80 (303.2)
5' 70 (265.3)
10' 48 (181.9)
20' 0 (0)

Order Information


VCMA-20 Series Condensate Pump

Item Model Volts Shut-Off Safety Switch Tubing Included
554435 VCMA-20ULST 115 VAC 20 ft Yes Yes
554421 VCMA-20UL 115 VAC 20 ft No No
554425 VCMA-20ULS 115 VAC 20 ft Yes No
554461 VCMA-20ULST 230 VAC 17 ft Yes Yes
554451 VCMA-20UL 230 VAC 17 ft No No
554455 VCMA-20ULS 230 VAC 17 ft Yes No

Support Materials


Brochures

Title Type Size
HVAC Selection Tool PDF 0.78 MB

Catalogs

Title Type Size
HVAC Catalog PDF 4.05 MB

Assets

Parts & Accessories


CV-10 Check Valve

Item Model Description
599065 CV-10 Check Valve for VCL Condensate Pump for 3/8" vinyl tubing

CV-14/24 Check Valve

Item Model Description
599069 CV-14/24 CV-14/24, Check Valve

CV-15/20 Check Valve

Item Model Description
599063 CV-15/20 CV-15/20 Brass Check Vlave for VCMA, VCC and VCL-24 Pump
