6EC Series Sump & Light Effluent Pump
6EC Series Sump & Light Effluent Pump
Continuous duty rated for sump & light effluent applications, the submersible 6EC Series sump and light effluent pump is for use in basins or lift stations and are suitable for pumping clear water or effluent gray water with up to 1/2" spherical semi-solids.
Features & Benefits
- 1/3 horsepower PSC motor
- Heavy-duty cast iron construction
- 1-1/2" FNPT discharge (38mm)
- Multiple automatic switch options
- 140 °F (60 °C) liquid temperature rating
- Ideal for basement sump and light effluent applications
Overview
Little Giant 6EC Series sump and light effluent pump features 1/3 horsepower Permanent Split Capacitor (PSC) motors providing lower current draw, energy efficiency, improved performance, and cooler-running for durability. The 6EC Series sump and light effluent pump offers multiple switch options for automatic operation. Built on the industry's best 6E platform, the 6EC Series consumes only 5.0 amps while producing 53 gpm @ 5' of head and reaching a maximum shut-off of 28'. Available with either 10' or 20' power cords.
Specifications
| Capacity | 53 gpm @ 5' |
| Shut Off | 28' (8.5 m) |
| Max. Liquid Temp. | 140 °F (60 °C) |
| Discharge | 1-1/2" (38.1 mm) |
| Impeller | Nylon |
| Electrical | 115 V, 60 Hz, 5 A |
| Operation | Automatic or Manual |
Performance
| Head | GPM (LPM) |
| 5' | 53 (200.6) |
| 10' | 50 (189.3) |
| 15' | 42 (159) |
| 20' | 34 (128.7) |
Order Information
6EC Series Sump & Light Effluent Pump with Polypropylene Base
| Item | Model | Volts | Switch Type | Cord Length | Discharge |
|---|---|---|---|---|---|
| 506801 | 6EC-CIM | 115 VAC | Manual | 10 ft | 1.5 " |
| 506802 | 6EC-CIM | 115 VAC | Manual | 20 ft | 1.5 " |
| 506803 | 6EC-CIA-RF | 115 VAC | Piggyback Mechanical Float | 10 ft | 1.5 " |
| 506807 | 6EC-CIA-SFS (10 Ft.) | 115 VAC | Integral Snap-Action Float | 10 ft | 1.5 " |
| 506804 | 6EC-CIA-SFS | 115 VAC | Integral Snap-Action Float | 20 ft | 1.5 " |
| 506808 | 6EC-CIA-RF | 115 VAC | Piggyback Mechanical Float | 30 ft | 1.5 " |
| 506809 | 6EC-CIA-DS | 115 VAC | Integral Diaphragm | 10 ft | 1.5 " |
| 506810 | 6EC-CIA-DS | 115 VAC | Integral Diaphragm | 18 ft | 1.5 " |
| 506811 | 6EC-CBA-SFS | 115 VAC | Integral Snap-Action Float | 20 ft | 1.5 " |
| 506812 | 6EC-CBM | 115 VAC | Manual | 20 ft | 1.5 " |
6EC Series Sump & Light Effluent Pump with Cast Iron Base
| Item | Model | Volts | Switch Type | Cord Length | Discharge |
|---|---|---|---|---|---|
| 506858 | 6EC-CIA-RF | 115 VAC | Piggyback Mechanical Float | 20 ft | 1.5 " |
